Cygnus® 2

为 OLED 应用提供可能的最佳测量精度

OLED 应用提供最佳测量精度

Cygnus 2 薄膜沉积控制器在 INFICON 薄膜沉积控制器可靠成熟的性能基础上，增添了更多独特的功能，可帮助您实现 OLED 过程的最大价值。Cygnus 2 使用我们 ModeLock 频率测量系统，提供稳定、高分辨率的速率和厚度测量，速率分辨率可达每 1/10 秒 0.00433 Å/s，是行业中的佼佼者。Cygnus 2 具有其他石英晶体控制器无法比拟的性能、品质和功能，赋予您的过程卓越的可重复性。

功能

INFICON ModeLock 技术确保获得最高、最稳定的速率和厚度测量分辨率，即使在速率极低的情况下
Auto Z 技术通过自动测定沉积材料的 Z 比值，可提高厚度测量的精度
一个 Cygnus 2 即可同时、单独或以任何组合方式控制最多 6 个来源，无需使用两个或三个控制器
彩色 TFT LCD 显示屏使用户很容易看到过程的进展状况
10 Hz 测量
100ms 样本速率下频率范围为 +/-0.0035 Hz
USB 数据存储功能可存储屏幕截图、配方存储和数据记录
多个源厚度合计功能
测量低密度、低速率材料的平均速率（使用稳定源的低速率 OLED 掺杂材料沉积最多 30 秒）
速率显示分辨率可达 0.001Å
4 米 XIU 选件能够在大型系统中使用较长的真空传感器电缆
无沉积控制允许持续控制源，因为基片可以通过沉积室不断循环
6 个标准 DAC 输出和另外 6 个可选输出用于来源控制、速率或厚度监控
可选以太网通信
符合 RoHS 标准

规格

测量性能
厚度和速率分辨率/测量 (1)	±0.00433 Å
测量频率范围	6.0 to 4.5 MHz (fixed)

过程配方和数据管理
材料计划	6 independent materials

来源数量 (2)	up to 6

(1) 工具/密度 = 100/1，基础频率 = 6 兆赫兹 (2) Cygnus 2 有 6 个 DAC 输出标准，还可选择再添加 6 个。可将 12 个中的任何一个配置为来源控制电压或记录器输出，但可同时控制的来源数量为 6

零件号

Accessories

Accessories and Replacement Parts

Consumables

Name	Description
Front Load Single Sensor	Front Load Single Sensor
Front Load Dual Sensor	Front Load Dual Sensor
Cool Drawer Single Sensor	Cool Drawer Single Sensor
Cool Drawer Dual Sensor	Cool Drawer Dual Sensor
Low Profile Single Sensor	Low Profile Single Sensor
Easy Rate Dual Sensor	Easy Rate Dual Sensor
Low Profile Dual Sensor	Low Profile Dual Sensor
ALD Sensor	ALD Sensor
UHV Bakeable Sensor	UHV Bakeable Sensor
Sputtering Sensor	Sputtering Sensor
CrystalSix® Sensor	CrystalSix® Sensor
Crystal 12® Sensor	Crystal 12® Sensor
Easy Rate Single Sensor	Easy Rate Single Sensor
RSH-600 Rotary Sensor	RSH-600 Rotary Sensor

Part Number	Description
779-220-G1	CrystalTwo® Switch, 15.2 cm (6 in.) BNC Cables
779-220-G2	CrystalTwo® Switch, 50.8 cm (20 in.) BNC Cables
Oscillator kits	(Includes oscillator and cables)
781-611-G15	XIU PKG with 4.6 m (15 ft.) cable - For use with Cygnus 2, IC6, or XTC/3
781-611-G30	XIU PKG with 9.1 m (30 ft.) cable - For use with Cygnus 2, IC6, or XTC/3
781-611-G50	XIU PKG with 15.2 m (50 ft.) cable - For use with Cygnus 2, IC6, or XTC/3
781-611-G100	XIU PKG with 30.5 m (100 ft.) cable - For use with Cygnus 2, IC6, or XTC/3
781-612-G15	4m XIU PKG with 4.6 m (15 ft.) XIU cable - Includes 4 m in-vacuum cable and 6 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-612-G30	4m XIU PKG with 9.1 m (30 ft.) XIU cable - Includes 4 m in-vacuum cable and 6 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-612-G50	4 m XIU PKG with 15.2 m (50 ft.) XIU cable - Includes 4 m in-vacuum cable and 6 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-612-G100	4m XIU with 30.5 m (100 ft.) XIU cable - Includes 4 m in-vacuum cable and 6 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-613-G15	4m XIU PKG with 4.6 m (15 ft.) XIU cable - Includes 3.5 m in-vacuum cable and 20 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-613-G30	4m XIU PKG with 9.1 m (30 ft.) XIU cable - Includes 3.5 m in-vacuum cable and 20 in. BNC (XIU to feedthough) cable - For use with Cygnus 2, IC6, or XTC/3
781-613-G50	4m XIU PKG with 15.2 m (50 ft.) XIU cable - Includes 3.5 m in-vacuum cable and 20 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
781-613-G100	4m XIU PKG with 30.5 m (100 ft.) XIU cable - Includes 3.5 m in-vacuum cable and 20 in. BNC (XIU to feedthrough) cable - For use with Cygnus 2, IC6, or XTC/3
Oscillator Only	(No cables included)
781-600-G1	XIU (oscillator) - For XIU to sensor head cable lengths of 15 to 183 cm (6 to 72 in.) - For use with Cygnus 2, IC6, or XTC/3
781-600-G2	XIU (oscillator) - for XIU to sensor head cable lengths of 3 to 4 m (118 to 157 in.) - For use with Cygnus 2 or IC6
Cables
755-257-G6	15.2 cm (6 in.) BNC cable, XIU to vacuum feedthrough
600-1261-P15	4.6 m (15 ft.) cable, Cgynus 2, IC6 or XTC/3 controller to XIU
600-1261-P30	9.1 m (30 ft.) cable, Cygnus 2, IC6 or XTC/3 controller to XIU
600-1261-P50	15.2 m (50 ft.) cable, Cygnus 2, IC6 or XTC/3 controller to XIU
600-1261-P100	30.5 (100 ft.) cable, Cygnus 2, IC6 or XTC/3 controller to XIU
