LDM150 and LDM150R are simple, reliable and safe solutions for standalone constant monitoring of ANY refrigerant gas. These monitors are a true "plug and play" option! See how these monitors fit any application.

LDM150 uses an integrated sensor for a compact, all-in-one solution.  LDM150R uses a remote sensor for applications where the sensor should be installed separately from the monitor.  See more details in the specifications tab.

Advantages

  • Remote and integrated sensor options
  • Low maintenance, single point calibrations
  • Easy field service
  • Three adjustable alarm setpoints
  • Low or high voltage operation
  • Three relay outputs tie to any system or device
  • Designed for any size application
  • Factory calibrated
  • Detects all CFCs, HFCs, HFOs, HCFCs and CFCs

Specifications

LDM150
LDM150R
LDM150R (R290)
Compatible refrigerants743-202-HFC: R22, R32, R134a, R404a, R407c, R410a, R422b, R448a, R449a, R452a, R452b, R454b, R507 (AZ50), R1234yf, and more
Alarm indicationThree alarm levels with relay outputs (5A)
Cable lengthNot included (user provided)
Power input12 - 24 V (AC/DC), 50 - 60 Hz
Certifications

CE

IP54

Compatible refrigerants743-203-HFC: R22, R32, R134a, R404a, R407c, R410a, R422b, R448a, R449a, R452a, R452b, R454b, R507 (AZ50), R1234yf, and more
Alarm indication

Three alarm levels with relay outputs (5A)

Integrated siren and flashing light

Cable lengthNot included (user provided)
Power input

12 - 24 V (AC/DC), 50 - 60 Hz

230 V (AC/DC) (High voltage models only)

Certifications

CE

IP67

Compatible refrigerantsR290 (propane), R600 (isobutane), R441a
Alarm indicationThree alarm levels with relay outputs (5A)
Cable length5m (16.5 ft.)
Power input12 - 24 V (AC/DC), 50 - 60 Hz
Certifications

CE

IP56

ATEX

Download full specifications
Part Number
Accessories
Spare Parts
LDM150
743-202-HFCLDM150 (Integrated sensor), for HFCs, CFCs, HCFCs, HFOs, and A2Ls
LDM150R
743-203-HFCLDM150R (Remote sensor), for HFCs, CFCs, HCFCs, HFOs, and A2Ls
743-600-G1MCT150 Calibration Tool (includes 743-706-G1)
743-707-G2Siren/flasher, blue
743-707-G1Siren/flasher, red
743-700-G1Replacement sensor for LDMR (CO2)
743-701-G1Replacement sensor for LDM150 (CO2)
743-704-G1Replacement sensor for LDM150/LDMR (HFC)
743-703-G1Replacement sensor for LDM150/LDM150R, NH3 (ammonia)
743-702-G1Replacement sensor for LDM150R (R290) w/ ATEX Cable
743-705-G1Replacement sensor module for MCT150, NH3 (ammonia)
743-706-G1Replacement Sensor module for MCT150 (HFC/R290)
