1. Pilot® Plus
Vacuum Gauge

Pilot® Plus

Superior Accuracy, Filter-Protected Sensor, and Extended Battery Life Provide More Jobsite Productivity

Pilot-Plus

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information

You can unsubscribe from these communications at any time. For more information please review our Privacy Policy.

Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!
Back

INFICON Pilot Plus Vacuum Gauge incorporates several innovative features for unsurpassed performance. Like the original Pilot Vacuum Gauge, its Pirani sensor provides greater accuracy and the ability to measure the entire vacuum process, from atmosphere down to one micron. You'll know instantly if your connections are vacuum-tight.

Features

  • Operates for 45 hours on one 9V battery
  • Quick calibration specific to local pressure
  • Displays in micron, Pascal, Torr or millibar
  • Low battery indicator
  • Plastic storage case included
  • 1-year replacement warranty
  • Made in the USA

Advantages

  • Innovative filter protects sensor, eliminates need for cleaning
  • Measures from atmosphere to 1 micron
  • Auto shut-off after 60 minutes to conserve battery
  • Pirani sensor for better accuracy
  • Large, easy-to-read LCD display

Typical Applications

  • Vacuum measurement in HVAC/R service

Specifications

Base unit includes9V battery, filters, storage case
Power source(1) 9V alkaline battery, included
Display unitsmicrons, Pascal, millibar, Torr
Display rangeatm (760,000 microns) to 1 micron (0.01 mbar, 0.001 Torr, 1 Pa)
Download full specifications
Part Number
Consumables
710-202-G1Pilot Plus with 1/4" refrigerant flare fitting
710-202-G27Pilot Plus with KF-16 fitting
710-701-G1Pilot Plus Spare Filters (quantity 5; for 710-202-G1 only)
